Mahsulot tavsifi
| Xususiyatlar | |
| Model | ZGSM-FGD200H4 |
| Tovar belgisi | Lumileds 3030 |
| Drayv markasi | Meanwell HLG seriyali |
| Oddiy kuchlanish | 200W |
| LED modul miqdori | 5 ta modul |
| Kirish voltaji | 100-240 / 277VAC |
| Quvvat samaradorligi | > 90% |
| Quvvat omili | > 0,95 |
| Yoritgichli nurli samaradorlik | > 120 lm / g |
| Chiroqli Lumen chiqishi | 24,000 lm (Lümen bardoshlik +/- 5%) |
| Rangni qiyoslash indeksi | Ra> 70 |
| Rang harorati | 3000K, 4000K, 5000K yoki 5700K |
| Fotometrik toifa | 60,90,110 daraja |
| Optimal ish harorati | 25 ℃ |
| Saqlash harorati | '-40 ℃ ~ + 70 ℃ |
| Mehnat muhiti | 40 ° S dan + 50 ° S, 10% ~ 90% RH oralig'ida |
| Total Harmonik Distortion | <> |
| Lumen xizmati | > 75,000 soat -L70, @ 25 ºC (77 ºF) |
| Tana va qobiq materiallari | Anodlangan alyuminiy |
| IP reytingi | IP66 sinov hisoboti bilan |
| IK Rating | IK10 sinov hisoboti bilan |
| Sertifikatlash | Idoralar, ROHS, IOS9001, ISO14001, LM80 |
| Majburiy emas funktsiya | 1-10V DC yoki PWM Signalning yoki qarshilikning qisqartirilishi |
| Taymer / Photocell nazorati | |
| Kafolat | 7 yil |
| Paket tafsilotlari | |
| Vaqt o'lchami | 585 x340 x332 mm |
| Fikstür vazn | 7,0 kg / 15,4 lbs |
| Paket o'lchami | 635 x365 x160 mm |
| Paket og'irligi | 8,1 kg / 17,9 lbs |
